Inside station building

Fire fighting equipment

CO2 Facility

Firefighting facility in preparation of
the fire in the electric room

Complex high brightness exit sign

Evacuation facility containing high brightness exit sign,
emergency broadcasting facility and visual alarm system

Sprinkler

Firefighting facility which sprays water
when a fire takes place

Indoor fireplug

A facility which extinguishes fire displaying hose
and nozzle when a fire takes place

Fire extinguisher

How to use fire extinguisher

Pull the lever to take out the fire extinguisher
Approach the fire extinguisher nearly (3-5m) to the fire (fire point)
Take the safety pin out and forward the nozzle to the fire
Press the handle hard and spray from the front as if sweep the broom leaning against wind.

gas mask

How to use gas mask

Open the package and pull gas mask out
Wear the gas mask with lens side down while stopping your breath
Fasten the head belt to the adequate length
Breath covering the filter with hand to check if the air leaks or not

How to use evacuation exit

Please evacuate to the tunnel using emergency stepladder when it is difficult to evacuate to the waiting room in the emergency
- Support lower part of the emergency stepladder beneath the rail and put the upper part on floor of the platform
You may use an emergency stepladder only in the emergency

Railway using lifesaving equipment

What’s trolley?

The equipment which may evacuate the elderly, child or injured who are difficult to evacuate outside subway in the tunnel in the emergency using trolley

How to use trolley

1. Open a folded trolley on the rail maintaining horizontal
2. Insert the handle② and fixing pin③ into the right position with opposite angle each other
3. Place the fixing plate④ on center of the trolley① and place each 2 plates⑤ on the left and right sides
4. Grasp the brake lever⑥ attached to side of the handle together with handle and move it back and forward to operate
※ Store it in the store box disassembling in apposite order of the opening after use

Displayed in the platform
Installed on the railway
